Fast Chat AI - RAG Chatbot

Intelligent document-grounded chatbot with multi-LLM support

2025

AI & Machine Learning

In-progress

Python FastAPI React TypeScript PostgreSQL Redis Docker

View Code

In a nutshell: I built a chatbot that answers questions by searching through your uploaded documents.

Project Overview

Fast Chat AI is a full-stack RAG chatbot that enables users to upload documents (PDF, TXT, DOCX, Markdown) and have intelligent conversations grounded in their specific knowledge base. The application uses vector embeddings stored in PostgreSQL with pgvector for semantic search, ensuring responses are accurate and contextually relevant.

The system supports multiple LLM providers (OpenAI, Anthropic, Google AI) with automatic failover and cost-optimized provider selection. Conversation memory uses a hybrid Redis + PostgreSQL architecture with auto-summarization to maintain context across long conversations.

The application features multi-tenant environment management with isolated knowledge bases, role-based access control, and a modern React frontend with TypeScript and Tailwind CSS.

Technical Specifications

Technologies Used

Python

FastAPI

React

TypeScript

PostgreSQL

Redis

Docker

Project Details

Category

AI & Machine Learning

Development Year

2025

Status

In Progress

Code Examples

def process_data(input_data):
    """Process input data using advanced algorithms"""
    processed = []
    for item in input_data:
        result = complex_algorithm(item)
        processed.append(result)
    return processed

Performance Metrics

Technical Challenges & Solutions

Problem

Ensuring accurate responses grounded in uploaded documents rather than LLM hallucinations

Solution

Implemented RAG pipeline with pgvector semantic search and intelligent document chunking to retrieve relevant context before generating responses

Technologies Used:

pgvector PostgreSQL Embedding Models

Problem

Managing costs and reliability across multiple LLM providers

Solution

Built a provider abstraction layer with automatic failover and cost-optimized routing between OpenAI, Anthropic, and Google AI

Technologies Used:

OpenAI API Anthropic API Google AI API

Problem

Maintaining conversation context across long interactions without exceeding token limits

Solution

Developed hybrid memory architecture using Redis for short-term context and PostgreSQL for long-term storage with auto-summarization

Technologies Used:

Redis PostgreSQL Summarization

Project Impact

<1s

Semantic Search

3

LLM Providers

Multi-tenant

Environment Support

Project Gallery

View Image

RAG pipeline: FastAPI + pgvector + multi-LLM providers

View Image

Streaming responses with source citations from uploaded documents

View Image

Intelligent document chunking with vector embedding indexing

Loading...

1 / 3

Detailed Project Documentation

Background & Context

Fast Chat AI is a Retrieval-Augmented Generation (RAG) chatbot application that lets users upload documents and have intelligent conversations grounded in their specific knowledge base. Rather than relying solely on an LLM’s training data, every response is backed by semantic search across the user’s uploaded documents, ensuring accuracy and relevance.

The project was built to explore the full RAG pipeline end-to-end: document processing, vector embeddings, semantic retrieval, and LLM-powered generation – all wrapped in a production-ready full-stack application.

Problem Statement

Large Language Models are powerful but suffer from key limitations when used in knowledge-intensive tasks:

• Hallucination: LLMs can generate plausible-sounding but incorrect information
• Stale Knowledge: Training data has a cutoff date and cannot include private documents
• No Source Attribution: Users cannot verify where information comes from
• Cost Variability: Different providers offer different price/quality tradeoffs
• Context Limits: Long conversations lose important earlier context

Solution Approach

Fast Chat AI addresses these challenges through a comprehensive RAG architecture:

1. Document-Grounded Responses: Every answer is retrieved from the user’s own uploaded documents via semantic search
2. Multi-Provider LLM Support: Automatic failover and cost-optimized routing across OpenAI, Anthropic, and Google AI
3. Hybrid Conversation Memory: Redis for fast short-term context, PostgreSQL for persistent long-term memory with auto-summarization
4. Multi-Tenant Environments: Isolated knowledge bases per user/project
5. Role-Based Access Control: Admin and chat user roles for secure multi-user deployment

Technical Architecture

System Overview

The application follows a three-tier architecture:

Backend (FastAPI + Python)

• RESTful API with async request handling via FastAPI
• SQLAlchemy 2.0 with async PostgreSQL driver
• Alembic for database migrations
• LLM provider abstraction layer with failover logic

Vector Store (PostgreSQL + pgvector)

• Document embeddings stored alongside relational data
• Semantic similarity search using cosine distance
• Intelligent document chunking for optimal retrieval

Frontend (React + TypeScript)

• React 19 single-page application
• React Router v7 for client-side routing
• Tailwind CSS v4 for utility-first styling
• Vite 7 for fast development and optimized builds

Core Components

Document Processing Pipeline

• Supports PDF, TXT, DOCX, and Markdown file formats
• Intelligent chunking that respects document structure
• Embedding generation using provider APIs
• Metadata extraction for enhanced search filtering

RAG Retrieval Engine

• Vector similarity search via pgvector
• Configurable retrieval parameters (top-k, similarity threshold)
• Context window assembly from retrieved chunks
• Source attribution for every response

LLM Provider Manager

• Abstract interface supporting OpenAI, Anthropic, and Google AI
• Automatic failover when a provider is unavailable
• Cost-optimized provider selection based on query complexity
• Streaming response support for real-time output

Conversation Memory System

• Redis-backed short-term memory for active sessions
• PostgreSQL-backed long-term conversation history
• Auto-summarization to condense long conversations
• Context injection for maintaining coherent multi-turn dialogue

Key Features

Document Management

• Multi-Format Upload: PDF, TXT, DOCX, and Markdown support
• Intelligent Chunking: Structure-aware splitting for better retrieval
• Environment Isolation: Separate knowledge bases per project or tenant
• Real-Time Processing: Documents available for querying immediately after upload

Conversation Interface

• Streaming Responses: Real-time token-by-token output display
• Source Citations: Every response links back to source document chunks
• Conversation History: Persistent chat history with search
• Context Awareness: Maintains understanding across multi-turn conversations

Multi-LLM Intelligence

• Provider Selection: Choose between OpenAI, Anthropic, or Google AI
• Automatic Failover: Seamless switching when a provider is unavailable
• Cost Optimization: Intelligent routing based on query complexity
• Model Configuration: Adjustable temperature, max tokens, and other parameters

Administration

• Role-Based Access: Admin and user roles with different permissions
• Environment Management: Create and manage isolated knowledge bases
• Usage Monitoring: Track token usage and costs across providers
• User Management: Multi-user support with secure authentication

Technical Stack

Layer	Technology	Purpose
Backend Framework	FastAPI	Async REST API
Language	Python 3.11+	Backend logic
Database	PostgreSQL 15 + pgvector	Data + vector storage
Cache	Redis 7	Session memory + caching
ORM	SQLAlchemy 2.0 (async)	Database abstraction
Migrations	Alembic	Schema versioning
Frontend	React 19 + TypeScript	User interface
Styling	Tailwind CSS v4	UI design
Build Tool	Vite 7	Frontend bundling
Containerization	Docker Compose	Service orchestration
LLM Providers	OpenAI, Anthropic, Google AI	Language models

Development Setup

Backend

# Create virtual environment
python3 -m venv .venv
source .venv/bin/activate

# Install dependencies
pip install -r requirements.txt

# Start PostgreSQL and Redis
docker compose up -d

# Run database migrations
alembic upgrade head

# Start the server
make run

Frontend

cd frontend
npm install
npm run dev
# Access at http://localhost:5173

Testing Strategy

The project includes comprehensive test coverage:

• Unit Tests: Individual component and service testing
• Integration Tests: API endpoint and database interaction testing
• End-to-End Tests: Full RAG pipeline validation
• Provider Tests: LLM provider failover and response quality testing

Challenges & Solutions

Challenge 1: Retrieval Accuracy

Problem: Ensuring the RAG pipeline retrieves the most relevant document chunks for each query Solution:

• Implemented intelligent chunking that respects document structure (headings, paragraphs, code blocks)
• Tuned embedding parameters and similarity thresholds through systematic evaluation
• Added metadata filtering to narrow search scope when context is available

Challenge 2: Multi-Provider LLM Management

Problem: Different LLM providers have different APIs, capabilities, pricing, and failure modes Solution:

• Built an abstract provider interface that normalizes interactions across OpenAI, Anthropic, and Google AI
• Implemented automatic failover with configurable retry logic
• Added cost-based routing to optimize spend without sacrificing quality

Challenge 3: Conversation Memory at Scale

Problem: Long conversations exceed LLM context windows, causing loss of earlier context Solution:

• Designed hybrid memory using Redis for fast access to recent messages and PostgreSQL for long-term persistence
• Implemented auto-summarization that condenses earlier conversation turns into compact summaries
• Injected relevant memory context into each prompt without exceeding token limits

Future Enhancements

• Advanced RAG Techniques: Hypothetical Document Embeddings (HyDE), re-ranking, and query expansion
• Evaluation Framework: Automated RAG quality metrics (faithfulness, relevance, recall)
• Collaborative Environments: Shared knowledge bases with team-level permissions
• Webhook Integrations: Connect to Slack, Teams, and other messaging platforms
• Fine-Tuned Models: Custom model training on domain-specific document collections
